API 6A Lift Type Check Valve

ID:142

Main features

Reliable seal, and the more pressure the better sealing
Small vibration noise
The sealing surface between gate and body is welded with hard alloy, which has good wear resistance performance
The check valve structure can be Lift type
Flow direction stamp on the body
End connections: API 6A flange type or API 5B threaded

API 6A Lift Type Check Valve

Product Specification

Sizes: 1-13/16" to 4-1/16"
Pressure Ranges: 2,000 psi to 15,000 psi
Product Specification Level: PSL-1,PSL-2,PSL-3,PSL-3G
Material Classes: AA,BB,CC,DD,EE,FF,HH
Temperature Rating: K to U (-60oC to 121oC)

Product Description

Lift type check valves are all position check valve, as the assembly can be done on horizontal, vertical ascending or descending position.

Enerpal manufactures lift type Check Valves that feature a compact and simple design that is perfect for manifold assemblies. Available in sizes from 1-13/16" through 4-1/16" and working pressures from 2,000 PSI to 15,000 PSI.

Applications

Used to control fluid flow and pressure at the Wellhead and Christmas tree equipment
Manage drilling fluid flow and pressure on high-pressure kill manifolds
High-pressure injection and kill lines for fracturing operations

We also supply other types of check valves, Swing Check Valve, Top Entry Check Valve, Flapper Type Check Valve, R Type Check Valve. Click on the product name to view details.
